FEATURES:
- Stable output power
- 5 Power levels up to 800mW;
- 48 Channels (including Raceband)
- Fast frequency lock, no startup interference with other pilots
- Built-in output power self-check functionality
- VTX telemetry with IRC Tramp protocol
SPECIFICATIONS:
- Input voltage: 7V～36V (@12V/380mA@800mW)
- Video standard: NTSC /PAL
- Output voltage/ Max current: 5V 1A
- Power levels: PIT/25mW/100mW/400mW/800mW
- Power draw @12V input current: 40mA@PIT MODE, 95mA@25mW, 185mA@100mW，250mA@400mW, 380mA@800mW
- Channels: 48 (including Raceband)
- Small size: 36*36*3mm
- Mounting pattern: 30.5x30.5 (4x M3)
- Lightweight: 7.5g (excluding antenna)
- VTX telemetry: IRC Tramp
- IRC Tramp VTX table values: 25/25mW, 100/100mW, 400/400mW, 600/800mW
INCLUDES:
- SucceX Force 800mW adjustable VTX x 1pc
- MMCX to SMA Female pigtail 100mm x 1pc
- 5.8GHz MMCX whip antenna 65mm x 1pc
- SH1.0 6P cable 100mm x 1pc
